Technical Data
Connection	10-32 UNF Ports
Filtration	25 Micron
Flow	8.0 CFM @ 60 PSI (4.2) Cv .12
Lubrication	None required
Medium	Compressed air; inert gasses
Sensing Pressure Range	2 - 25 PSI (.14 - 1.72)
Hysteresis	2 PSI @ 25 PSI, .5 PSI @ 2 PSI (.14 @ 1.72, .03 @ .14)
Accuracy	Rising or falling +/- .009 PSI (.0006) of the set point.
Temperature	-35 F (-37) to 150 (66)
Weight	.7 lbs. (261g)

Materials
Shaft adjuster	303 Stainless Steel
Mounting Screws and brackets	Stainless Steel
Seals	Buna N
Body and Cover	30% Glass filled Noryl® Resin
Valve body	Glass filled Noryl® Resin

Pressure Sensing
Apply sensing line to port 3 and pressurize. A small audible unpressurized bleed exits port 1A.
When the desired pressure is achieved Port 1A pressurizes
shifting any remote Air Pilot Spring return valve.
This valve is not included with this sensor.
To reset, vent the sensing line and then re-apply.
